k8s二进制升级从1.14.2至1.16.2

升级前准备

master节点组件: kubectl，kube-apiserver，kube-controller-manager，kube-scheduler

node节点组件:kube-proxy，kubelet

##暂不升级的组件,需要升级后面再单独升级

数据库组件:etcd

网络组件:flannel

二进制包下载：https://github.com/kubernetes/kubernetes/releases

开始升级升级kubectl

备份kubectl，在所有的master节点操作

[root@bjxg-sy-test bin]# cd /opt/k8s/bin
[root@bjxg-sy-test bin]# mv kubectl kubectl.bak.v1.12
[root@bjxg-sy-test opt]# mkdir /opt/k8s.1.16.2-client
[root@bjxg-sy-test k8s.1.16.2-client]# cd /opt/k8s.1.16.2-client
[root@bjxg-sy-test k8s.1.16.2-client]# tar -zxvf kubernetes-client-linux-amd64.tar.gz

分发kubectl到所有节点

source /opt/k8s/bin/environment.sh
for node_ip in ${NODE_IPS[@]}
  do
    echo ">>> ${node_ip}"
    scp kubernetes/client/bin/kubectl root@${node_ip}:/opt/k8s/bin/
    ssh root@${node_ip} "chmod +x /opt/k8s/bin/*"
  done

查看kubectl版本


[root@bjxg-sy-test k8s.1.16.2-client]# kubectl version
Client Version: version.Info{Major:"1", Minor:"16", GitVersion:"v1.16.2", GitCommit:"c97fe5036ef3df2967d086711e6c0c405941e14b", GitTreeState:"clean", BuildDate:"2019-10-15T19:18:23Z", GoVersion:"go1.12.10", Compiler:"gc", Platform:"linux/amd64"}
Server Version: version.Info{Major:"1", Minor:"14", GitVersion:"v1.14.2", GitCommit:"66049e3b21efe110454d67df4fa62b08ea79a19b", GitTreeState:"clean", BuildDate:"2019-05-16T16:14:56Z", GoVersion:"go1.12.5", Compiler:"gc", Platform:"linux/amd64"}

client版本是kubectl执行文件的版本.
server版本是kube-apiserver执行文件的版本.
升级master节点组件

在master节点操作，另需要注意一台master节点一台操作，如果是用的keepalived做的vip高可用，需要先让vip漂移；如果是nginx的4层代理，需要先将要升级的master节点摘掉。

systemctl stop kube-apiserver
systemctl stop kube-scheduler
systemctl stop kube-controller-manager

mv /opt/k8s/bin/kube-apiserver{,.bak.v1.12}
mv /opt/k8s/bin/kube-controller-manager{,.bak.v1.12}
mv /opt/k8s/bin/kube-scheduler{,.bak.v1.12}
mv /opt/k8s/bin/kubeadm{,.bak.v1.12}

mkdir /opt/k8s.1.16.2-server
cd /opt/k8s.1.16.2-server
tar -zxvf kubernetes-server-linux-amd64.tar.gz

复制新版本客户端

source /opt/k8s/bin/environment.sh
for node_ip in ${NODE_IPS[@]}
  do
    echo ">>> ${node_ip}"
    scp kubernetes/server/bin/kube-apiserver root@${node_ip}:/opt/k8s/bin/
    scp kubernetes/server/bin/{kube-controller-manager,kube-scheduler,kubeadm} root@${node_ip}:/opt/k8s/bin/
    ssh root@${node_ip} "chmod +x /opt/k8s/bin/*"
  done

启动服务 kube-apiserver

[root@bjxg-sy-test k8s.1.16.2-server]# systemctl status kube-apiserver
● kube-apiserver.service - Kubernetes API Server
   Loaded: loaded (/etc/systemd/system/kube-apiserver.service; enabled; vendor preset: disabled)
   Active: active (running) since Wed 2020-04-15 14:52:14 CST; 39s ago
     Docs: https://github.com/GoogleCloudPlatform/kubernetes
 Main PID: 11427 (kube-apiserver)
    Tasks: 13
   Memory: 340.5M
   CGroup: /system.slice/kube-apiserver.service
           └─11427 /opt/k8s/bin/kube-apiserver --advertise-address=10.16.16.11 --default-not-ready-tolerati...

看下kubectl version

[root@bjxg-sy-test k8s.1.16.2-server]# kubectl version
Client Version: version.Info{Major:"1", Minor:"16", GitVersion:"v1.16.2", GitCommit:"c97fe5036ef3df2967d086711e6c0c405941e14b", GitTreeState:"clean", BuildDate:"2019-10-15T19:18:23Z", GoVersion:"go1.12.10", Compiler:"gc", Platform:"linux/amd64"}
Server Version: version.Info{Major:"1", Minor:"16", GitVersion:"v1.16.2", GitCommit:"c97fe5036ef3df2967d086711e6c0c405941e14b", GitTreeState:"clean", BuildDate:"2019-10-15T19:09:08Z", GoVersion:"go1.12.10", Compiler:"gc", Platform:"linux/amd64"}
[root@bjxg-sy-test k8s.1.16.2-server]#

启动kube-controller-manager和kube-scheduler

systemctl start kube-controller-manager && systemctl start kube-scheduler
升级node节点组件

在所有node节点执行

systemctl stop kubelet
systemctl stop kube-proxy

mv /opt/k8s/bin/kubelet{,.bak.v1.12}
mv /opt/k8s/bin/kube-proxy{,.bak.v1.12}

拷贝二进制文件

source /opt/k8s/bin/environment.sh
for node_ip in ${NODE_IPS[@]}
  do
    echo ">>> ${node_ip}"
    scp kubernetes/server/bin/{kubelet,kube-proxy} root@${node_ip}:/opt/k8s/bin/
    ssh root@${node_ip} "chmod +x /opt/k8s/bin/*"
  done

在kubernetes 1.15版起kubelet需要删除allow-privileged这个参数，因为新版本中这个参数已经过时。我们只需要在kubelet启动脚步中删除即可

sed -i '/allow-privileged/d'  /etc/systemd/system/kubelet.service
systemctl daemon-reload && systemctl start kubelet
systemctl start kube-proxy
查看并验证

查看node节点

[root@bjxg-sy-test k8s.1.16.2-server]# kubectl get node
NAME           STATUS   ROLES    AGE   VERSION
bjxg-sy-test   Ready    <none>   27h   v1.16.2

启动一个pod

[root@bjxg-sy-test k8s.1.16.2-server]# kubectl create deploy nginx --image=nginx
deployment.apps/nginx created
[root@bjxg-sy-test k8s.1.16.2-server]# kubectl get pods
NAME                     READY   STATUS              RESTARTS   AGE
nginx-86c57db685-hzsxk   0/1     ContainerCreating   0          5s

至此，k8s集群升级完毕
